As
substations evolve toward digitalization, understanding how data flows
from field devices to the SCADA control center is crucial. This blog
unpacks the real-time data journey—from the high-voltage yard to the SCADA
system, including the key devices, protocols, and communication
architecture involved.
1. Substation Yard – Source of Primary Data
At the
heart of any substation lie the high-voltage (HV) and low-voltage (LV)
sides. Data originates from:
- Incoming lines (33kV / 66kV
/ 132kV / 220kV)
- Outgoing feeders (1 to 4)
- Primary equipment:
- Lightning Arresters
- Isolators
- Current Transformers (CTs)
- Potential Transformers (PTs)
- Power Transformers (PTRs)
These
components provide voltage, current, and status signals used for
protection, measurement, and control.
2. Intelligent CRP Panels – Protection & Interface Layer
Each
outgoing feeder is connected to a Control and Relay Panel (CRP) which
includes:
- Multifunction (MF) Energy
Meters
- Protection Relays
- Intelligent Electronic
Devices (IEDs)
Each IED
communicates over:
- Tx/Rx lines (Transmit/Receive)
- Connected to substation
RTU or SCADA Gateway
Purpose:
- Local decision-making (tripping/breaker
operation)
- Real-time data capture
(amps, volts, breaker status)
- Time-tagged event logs
3. Communication Network – Digital Backbone
Protocols
used:
Protocol |
Purpose |
IEC
61850 |
Peer-to-peer
GOOSE messaging and SV |
Modbus |
Metering
data acquisition |
IEC
60870-5-104 (IEC 104) |
SCADA
communication to remote SLDC/ALDC |
Networking
devices:
- RTU (Remote Terminal Unit)
- Main and Standby CPU
- Router
- Firewall
- Communication Tower (for WAN uplink)
- MPLS Connectivity (for secure Layer-3
IP-based communication)
4. Control Room – Substation SCADA Interface
Inside
the control room:
- FEP (Front-End Processor): Handles protocol
translation, typically IEC 104 to/from IEC 61850 or Modbus.
- SCADA Server: Stores and visualizes
real-time and historical data.
- Firewall: Ensures cyber-secure
communication.
- Redundant Architecture: Main + Standby CPUs for
fault tolerance.
5. Data Flow – Step-by-Step
A[Primary Equipment (CT/PT/CB/PTR)] -->
B[CRP Panel (IED, Relay, MF Meter)]
B --> C[RTU / Protocol
Converter]
C --> D1[FEP Server]
D1 --> D2[SCADA Server]
D2 --> E[SLDC / ALDC via
IEC 104]
6. Cybersecurity Considerations
- Firewalls isolate internal OT network
from external threats.
- MPLS ensures private WAN communication.
- IEC 62351 standards should be
followed to secure IEC 61850/104.
Conclusion
The data flow inside a modern substation is a carefully engineered pipeline of real-time signals, digital communication, and secure data acquisition, all working in tandem to support SCADA visibility, grid protection, and remote operations.Category: Substation
